Specifications
| Kilowatt | 1.8 kW |
| Length (L.1) | 219 mm |
| Mount Hole Center - Center (O.1) | 108 mm |
| Mount Hole Diameter (C.1) | 10.6 mm |
| Mount Hole Diameter (C.2) | 10.6 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 19 qty |
| Pinion at Rest (B) | 17 mm |
| Rotation | ACW |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ACURA | RLX | 3.5 | 2014, 2015, 2016, 2017 |
| HONDA | ACCORD | 3.5 | 2013, 2014, 2015, 2016, 2017 |
| HONDA | CROSSTOUR | 3.5 | 2013, 2014, 2015 |
Reference Information
31200-5G0A02, 31200-5G0A04, 5GO74, 312005G0A04, SM74011, 31200RL8A01, SM72001
Video/Publications
ARROWHEAD 410-54254R, SMU0568
HONDA 31200-5G0A02, 31200-5G0A04, 5GO74
J&N ELECTRICAL PRODUCTS 410-54254
LESTER 19252
MITSUBA SM740-11
70-2855 MXS824
120598192 PSH
312005G0A02 Honda
312005G0A04 Honda
SM74011 Mitsuba
120599192 PSH
31200RL8A01 Honda
SM72001 Mitsuba
