Associated Numbers
Arrowhead SMT0329 16-919
General Motors 92170721, 92182365
Lester 19099
Mitsubishi M000T35273, M000T35273ZC, M0T35272, M0T35272ZC, M0T35273
PIC Picture ID 1035089, 1035219
Youtech/PartRef 436833 706253 mxs341 snj506
m000t36471 S5390S S5405S S5480S 410-48302
m0t36471
Arrowhead SMT0329
General Motors 92170721, 92182365
Lester 19099
Mitsubishi M000T35273, M000T35273ZC, M0T35272, M0T35272ZC, M0T35273
PIC Picture ID 1035089, 1035219
Youtech/PartRef 436833 706253 mxs341 snj506
m000t36471
m0t36471
410-48275
UD20418S AS-PL
S-80462 DIXIE
92180353 HOLDEN
92182365 HOLDEN
92190142 HOLDEN
92204529 HOLDEN
STM5274 KRAUF
M000T35272 MITSUBISHIList
M000T35273 MITSUBISHIList
M000T35274 MITSUBISHIList
M000T35275 MITSUBISHI
M000T35276 MITSUBISHIList
M0T35272 MITSUBISHIList
M0T35273 MITSUBISHIList
M0T35274 MITSUBISHIList
M0T35275 MITSUBISHI
M0T35276 MITSUBISHIList
UNIT BOM 103-5078A WAI / TRANSPO
91-27-3441 WILSON
Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 192 mm |
| Mount Hole Center - Center (O.1) | 98 mm |
| Mount Hole Center - Center (O.2) | 23 mm |
| Mount Hole Center - Center (O.3) | 84 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 12.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 29.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 68 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HOLDEN | Various Models |
Alternatives >>>
S5390S - with push on lucar terminal for exciter/switch connection
S5405S - with 5mm stud connection for exciter/switch
S5480S - with push on lucar terminal for exciter/switch connection - 1.4kW version
410-48302 - with bespoke connector for exciter/switch connection
Reference Information
92170721 19099N M000T35272 UD21006S M0T35272Video/Publications
