Associated Numbers
0009067703 Mercedes-Benz
0009069405 Mercedes-Benz
0125812010 Bosch show
0125812011 Bosch show
0125812011OR +line
0125812011SEL +line
0986082140 Bosch ruil
0986082147 Bosch ruil
12090695 EuroTec
440924 Valeo
443271 Valeo
555943190 PSH
931584 EDR
A0009067703 Mercedes-Benz
A0009069405 Mercedes-Benz
DRA1584 Remy
LRA04093 Lucas
0125812010, 0125812011, 0125812057, 0125812058, 0125812063, 0125812064, 0986082140 KRAUF ALB6057AN, ALB8057AN Mercedes Benz A0009067703, A000906770380, A0009069305, A0009069405 Valeo 443271 WPS 20571N ZAUFER 301N20799Z
0009067703 0009069305 0125812010 0125812011 0125812057 0125812058 0125812063 0125812064 0986082140 12090695 2010591 28-7702 32082140 32118604 554800RIB 554801RIB 555.943.190.210 A0009067703 A0009069305 A0009069405 AEG1415 ALT175390 ALT175390A ALTJ161 ALTJ531 BOS0125812010 CAL10591GS DA2694 DRA1584 LRA04093 LRA4093 UD15002A UNIT BOM 220-5860
0009067703 Mercedes-Benz
0125812010 Bosch show
0125812011 Bosch show
0125812011OR +line
0125812011SEL +line
0986082140 Bosch ruil
0986082147 Bosch ruil
12090695 EuroTec
440924 Valeo
443271 Valeo
555943190 PSH
931584 EDR
A0009067703 Mercedes-Benz
DRA1584 Remy
LRA04093 Lucas
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 190 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 208 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60.5 mm |
| OEM Product | No |
| Plug Code | PL_2306 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 53 mm |
| Pulley to Mount Distance (A) | 33 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | C 160 1.6 | (S205)[M274.910] | 04.2015- |
| MERCEDES BENZ | C 160 1.6 | (W205)[M274.910] | 04.2015- |
| MERCEDES BENZ | C 180 1.6 | (A205)[M274.910] | 06.2016- |
| MERCEDES BENZ | C 180 1.6 | (C205)[M274.910] | 10.2015- |
| MERCEDES BENZ | C 180 1.6 | (S205)[M274.910] | 09.2014- |
| MERCEDES BENZ | C 180 1.6 | (W205)[M274.910] | 03.2014- |
| MERCEDES BENZ | C 200 2.0 | (A205)[M274.920] | 06.2016- |
| MERCEDES BENZ | C 200 2.0 | (C205)[M274.920] | 10.2015- |
| MERCEDES BENZ | C 200 2.0 | (S205)[M274.910] | 09.2014- |
| MERCEDES BENZ | C 200 2.0 | (W205)[M274.920] | 12.2013- |
| MERCEDES BENZ | C 200 2.0 4-Matic | (A205)[M274.920] | 06.2016- |
| MERCEDES BENZ | C 200 2.0 4-Matic | (C205)[M274.920] | 04.2016- |
| MERCEDES BENZ | C 200 2.0 4-Matic | (S205)[M274.920] | 04.2015- |
| MERCEDES BENZ | C 200 2.0 4-Matic | (W205)[M274.920] | 04.2015- |
| MERCEDES BENZ | C 250 2.0 | (A205)[M274.920] | 06.2016- |
| MERCEDES BENZ | C 250 2.0 | (C205)[M274.920] | 10.2015- |
| MERCEDES BENZ | C 250 2.0 | (S205)[M274.920] | 09.2014- |
| MERCEDES BENZ | C 250 2.0 | (W205)[M274.920] | 03.2014- |
| MERCEDES BENZ | C 300 2.0 | (A205)[M274.920] | 06.2016- |
| MERCEDES BENZ | C 300 2.0 | (C205)[M274.920] | 10.2015- |
| MERCEDES BENZ | C 300 2.0 | (S205)[M274.920] | 09.2015- |
| MERCEDES BENZ | C 300 2.0 | (W205)[M274.920] | 09.2015- |
| MERCEDES BENZ | E 200 2.0 | (A238)[M274.920] | 06.2017- |
| MERCEDES BENZ | E 200 2.0 | (C238)[M274.920] | 12.2016- |
| MERCEDES BENZ | E 200 2.0 | (S213)[M274.920] | 07.2016- |
| MERCEDES BENZ | E 200 2.0 | (W213)[M274.920] | 01.2016- |
| MERCEDES BENZ | E 200 2.0 4-Matic | (C238)[M274.920] | 06.2017- |
| MERCEDES BENZ | E 200 2.0 4-Matic | (S213)[M274.920] | 01.2017- |
| MERCEDES BENZ | E 200 2.0 4-Matic | (W213)[M274.920] | 07.2016- |
| MERCEDES BENZ | E 300 2.0 | (A238)[M274.920] | 06.2017- |
| MERCEDES BENZ | E 300 2.0 | (C238)[M274.920] | 12.2016- |
| MERCEDES BENZ | GLC 250 2.0 4-Matic | (C253)[M274.920] | 06.2016- |
| MERCEDES BENZ | GLC 300 2.0 4-Matic | (C253)[M274.920] | 10.2016- |
Reference Information
0009067703 0009069305 0009069405 0125812010 0125812011 0125812057 0125812058 0125812063 0125812064 28-7702 32082140 32118604 554800RIB 554801RIB 555.960.190 A0009067703 A0009069305 A0009069405 A0660S AEG1415 ALT125930 ALTJ161 ALTJ531 DA2708 DRA1598 LRA04093 LRA4093 UD15003A UNIT BOM 220-5860AVideo/Publications
0009067703 0009069305 0009069405 0125812010 0125812011 0125812057 0125812058 0125812063 0125812064 28-7702 32082140 32118604 554800RIB 554801RIB 555.960.190 A0009067703 A0009069305 A0009069405 A0660S AEG1415 ALT125930 ALTJ161 ALTJ531 DA2708 DRA1598 LRA04093 LRA4093 UD15003A UNIT BOM 220-5860AView your shopping basket or Browse other items in Alternators.
