Information
Associated Numbers
0121715049 0121715077 0121715149 0121715177 03G903016L 03G903016LX 03G903016N 03G903016NX 03L903023N 03L903024E 03L903024L 03L903024N 04L903024A 20017R 2015398 28-5764 305.901.180 439783 440415 553625RIB 553625RIV 554763RIV 89215537 8EL738213-411 9215537 A-6663 AEK3152 CAL15398 CAL15398AS CAL15398ES CAL15398GS CAL15398OS CAL15398RS DRA0674 EG18S015 FG18T079 FG18T103 FG18T123 FG18T124 LRA03152 SB343 VALFG18T079
ANV069GQ
012241091 Hella
03L903023N VW
03L903023NX VW
03L903024E VW
03L903024L VW
03L903024NX VW
04L903024AX VW
0986083850 Bosch ruil
12090437 EuroTec
2113571802 DRI
305901180 PSH
439783 Valeo
440415 Valeo
57541 EAI
617865 Valeo
9090811 Friesen
9090811F Friesen
930674 EDR
DRA0674 Remy
FG18T079 Valeo show
FG18T103 Valeo
FG18T123 Valeo show
FG18T123OR +line
FG18T124 Valeo
FGN18T079 Valeo show
HVW0009061000 Mercedes-Benz
LRA3152 Lucas
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 194 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Plug Code | PL_2306 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 50 mm |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 2.0 TDi | [CZHA] | 01.2015- |
| AUDI | A4 2.0 TDi | [DE..] | 01.2015- |
| AUDI | A4 2.0 TDi | [DF..] | 01.2015- |
| AUDI | A4 2.0 TDi Quattro | [CZHA] | 01.2015- |
| AUDI | A4 2.0 TDi Quattro | [DE..] | 01.2015- |
| AUDI | A4 2.0 TDi Quattro | [DF..] | 01.2015- |
| AUDI | A5 2.0 TDi | [DETA] | 01.2016- |
| AUDI | A6 2.0 TDi | [BNA] | 07.2004-03.2011 |
| AUDI | A6 2.0 TDi | [BRF] | 07.2004-03.2011 |
| AUDI | A6 2.0 TDi | [CAGA] | 01.2008-12.2011 |
| AUDI | A6 2.0 TDi | [CAGB] | 01.2008-12.2011 |
| AUDI | A6 2.0 TDi | [CAHA] | 01.2008-12.2011 |
| AUDI | A6 2.0 TDi | [CAHB] | 01.2008-12.2011 |
| SKODA | Octavia 1.6 TDi | [CLHA] | 01.2013- |
| SKODA | Octavia 1.6 TDi | [CLHB] | 01.2013- |
| SKODA | Octavia 1.6 TDi | [CRKB] | 01.2013- |
| SKODA | Octavia 1.6 TDi 4x4 | [CLHA] | 01.2014- |
| SKODA | Octavia 2.0 TDi | [CKF.] | 01.2013- |
| SKODA | Octavia 2.0 TDi | [CRV.] | 01.2013- |
| SKODA | Octavia 2.0 TDi | [CU..] | 01.2013- |
| SKODA | Octavia 2.0 TDi 4x4 | [CKFC] | 01.2012- |
| SKODA | Octavia 2.0 TDi 4x4 | [CUNA] | 01.2012- |
| SKODA | Octavia 2.0 TDi 4x4 | [CUPA] | 01.2012- |
| SKODA | Superb 2.0 TDi | [CRLB] | 01.2015- |
| SKODA | Superb 2.0 TDi | [DDAA] | 01.2015- |
| SKODA | Superb 2.0 TDi | [DFCA] | 01.2015- |
| SKODA | Superb 2.0 TDi | [DFEA] | 01.2015- |
| SKODA | Superb 2.0 TDi 4x4 | [CRLB] | 01.2015- |
| SKODA | Superb 2.0 TDi 4x4 | [DDAA] | 01.2015- |
| SKODA | Superb 2.0 TDi 4x4 | [DFCA] | 01.2015- |
| SKODA | Superb 2.0 TDi 4x4 | [DFEA] | 01.2015- |
| VW | Caravelle 2.0 TDi | [CAAB] | 01.2015- |
| VW | Caravelle 2.0 TDi | [CAAC] | 01.2015- |
| VW | Caravelle T6 2.0 TDi 4-Motion | [CAAC] | 01.2015- |
| VW | CC 3.6 | 01.2012-12.2014 | |
| VW | Crafter 2.0 TDi | [CKTB] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKTC] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKUB] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKUC] | 01.2011- |
| VW | Crafter 2.0 TDi | [CS..] | 01.2011- |
| VW | Crafter 2.0 TDi 4-Motion | [CKUB] | 01.2011- |
| VW | Crafter 2.0 TDi 4-Motion | [CSNA] | 01.2011- |
| VW | Golf VII 2.0 GTD | [CUNA] | 01.2013- |
| VW | Multivan 2.0 TDi | [CAA.] | 01.2012- |
| VW | Multivan 2.0 TDi | [CAAB] | 01.2015- |
| VW | Multivan 2.0 TDi | [CAAC] | 01.2015- |
| VW | Multivan 2.0 TDi | [CCH.] | 01.2012- |
| VW | Multivan 2.0 TDi | [CFCA] | 01.2012- |
| VW | Multivan 2.0 TDi 4-Motion | [CAA.] | 01.2012- |
| VW | Multivan 2.0 TDi 4-Motion | [CAAC] | 01.2015- |
| VW | Multivan 2.0 TDi 4-Motion | [CCH.] | 01.2012- |
| VW | Multivan 2.0 TDi 4-Motion | [CFCA] | 01.2012- |
| VW | Passat 1.6 TDi | [DCXA] | 01.2014- |
| VW | Passat 1.6 TDi | [DCZA] | 01.2014- |
| VW | Passat 2.0 TDi | [CRLB] | 01.2014- |
| VW | Passat 2.0 TDi | [DDAA] | 01.2014- |
| VW | Passat 2.0 TDi | [DFCA] | 01.2014- |
| VW | Passat 2.0 TDi 4-Motion | [CRLB] | 01.2014- |
| VW | Passat 2.0 TDi 4-Motion | [CUAA] | 01.2014- |
| VW | Passat 2.0 TDi 4-Motion | [DDAA] | 01.2014- |
| VW | Passat 2.0 TDi 4-Motion | [DFCA] | 01.2014- |
| VW | Passat 2.0 TDi 4-Motion | [DFEA] | 01.2014- |
| VW | Passat 3.6 FSi 4-Motion | [BWS] | 01.2011- |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CRLB] | 01.2015- |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CUAA] | 01.2015- |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [DDAA] | 01.2015- |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [DFCA] | 01.2015- |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [DFEA] | 01.2015- |
| VW | Transporter 2.0 TDi | [CAA.] | 01.2012- |
| VW | Transporter 2.0 TDi | [CAAB] | 01.2015- |
| VW | Transporter 2.0 TDi | [CAAC] | 01.2015- |
| VW | Transporter 2.0 TDi | [CCH.] | 01.2012- |
| VW | Transporter 2.0 TDi | [CFCA] | 01.2012- |
| VW | Transporter 2.0 TDi 4-Motion | [CAA.] | 01.2012- |
| VW | Transporter 2.0 TDi 4-Motion | [CAAC] | 01.2015- |
| VW | Transporter 2.0 TDi 4-Motion | [CCH.] | 01.2012- |
| VW | Transporter 2.0 TDi 4-Motion | [CFCA] | 01.2012- |
Reference Information
0121715049 0121715077 0121715149 0121715177 03G903016L 03G903016LX 03G903016N 03G903016NX 03L903023N 03L903024E 03L903024L 03L903024N 04L903024A 20017R 2015398 28-5764 305.901.180 439783 440415 553625RIB 553625RIV 554763RIV 89215537 8EL738213-411 9215537 A-6663 AEK3152 CAL15398 CAL15398AS CAL15398ES CAL15398GS CAL15398OS CAL15398RS DRA0674 EG18S015 FG18T079 FG18T103 FG18T123 FG18T124 LRA03152 SB343 VALFG18T079View your shopping basket or Browse other items in Alternators.
