Associated Numbers
DSN1423 S6492S
255236 Elstock
314068132 DRI
3696 CEVAM
4380001990 Denso
4380001991 Denso
4380001992 Denso
4380001993 Denso
4380001994 Denso
4380801993 Denso
450542132 PSH
DRS1033 Remy
DSN1423 Denso
GJ3211001AC Rover Group
GJ3211001AD Rover Group
GJ3211001AE Rover Group
LR070686 Rover Group
LR085507 Rover Group
LRS04073 Lucas
Specifications
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Kilowatt | 1.9 kW |
| Length (L.1) | 247 mm |
| Mount Hole Center - Center (O.1) | 163 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 23.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 69.5 mm |
| Voltage | 12 V |
Reference Information
88215113 CGB-55236 12374 255400D 450.542.132.261 336569 LR070686 PRSE499 STR70588 LRS4073 3696 LR085507 AEX1318 STRE499 GJ32-11001-AD GJ32-11001-AE GJ32-11001-AC 31004-OS 6040390.1 STN2713 450.542.132.050 LRS04073 DSN1423 25-5236 20432093OE 438000-1993 CST40390GS 6040390 20432093BN DRS1033 UD100748S 438000-1992 UD100746S 438000-1991 438080-1993 CST40390AS 438000-1990
