Associated Numbers
AAM-S6033 a3160
AEK2364 AUTOELECTRO
0121715020 BOSCH List
0986080090 BOSCH
114408 CARGO
CAL15294 CASCO
4651 CEVAM
DRA0144 DELCO
RAA11255 DELCO
EAA221182 EAA
57210 EAI
284870 ELSTOCK
210831 ERA
CA1937IR HC PARTS
6.3170.9 IKA
ALB1937 KRAUF
ALV1937 KRAUF
11.1937M LAUBER
LRA02364 LUCAS
944390903790 MAGNETI MARELLI
89213002 POWERMAX
9213002 POWERMAX
205.523.180 PSH
2542784 VALEO List
2542784A VALEO
2542784B VALEO
2542784C VALEO
437507 VALEO
439527 VALEO
TG17C020 VALEO List
TG17C022 VALEO List
059903015R VW
059903017K VW
06C903016J VW
20877NOE WAI / TRANSPO
23364N WAI / TRANSPO
23364R WAI / TRANSPO
ALT14164 WOODAUTO
VAL439527 WOODAUTO
0121715020
0121715120
059903015R
059903015RX
059903017K
06C903016J
0986080090
205523180
2542784
284870
437507
437535
439527
439541
542784
542801
6388SP
747052
9090379F
9090400F
930144
ALT0064sa
CA1937IR
DRA0144
HCA1937IR
KTR411046360
LRA02364
TG17C020
TG17C022
0121715020 059903015R 059903017K 059903017k 06C903016J 0986080090 11.1937M 114408 2015294 205.523.180 20877N-OE 210831 23364N 23364R 2542784 2542784A 2542784B 2542784C 28-4870 301937RI 301937RIV 437507 439527 4651 57210 6.3170.9 89213002 9213002 944390903790 A3160 AEK2364 ALB1937 ALT14164 ALV1937 CA1937IR CAL15294 CAL15294AS CAL15294ES CAL15294GS CAL15294OS CAL15294RS DRA0144 EAA-221182 LRA02364 RAA11255 TG17C020 TG17C022 VAL439527
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
Amp | 180 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 8.5 mm |
Diameter (D.2) | 8.5 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Length (L.1) | 180 mm |
Mount Inside Length or Pad Mount C-C (C) | 61 mm |
OEM Product | No |
Plug Code | PL_2303 |
Product Line | +Plus Line Pro |
Product Type | Brand new |
Pulley Grooves | 6 qty |
Pulley Outside Diameter (O.D.1) | 56.5 mm |
Pulley to Mount Distance (A) | 31 mm |
Pulley Type | SOLID |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A6 2.7 TDi | [BPP] | 03.2005-10.2008 |
AUDI | A6 2.7 TDi | [BSG] | 03.2005-08.2011 |
AUDI | A6 2.7 TDi | [CANB] | 03.2005-08.2011 |
AUDI | A6 2.7 TDi Quattro | [BPP] | 11.2004-10.2008 |
AUDI | A6 2.7 TDi Quattro | [BSG] | 06.2005-08.2011 |
AUDI | A6 2.7 TDi Quattro | [CAND] | 06.2005-08.2011 |
AUDI | A6 3.0 TDi | [ASB] | 06.2006-03.2011 |
AUDI | A6 3.0 TDi Quattro | [ASB] | 06.2006-10.2008 |
AUDI | A6 3.0 TDi Quattro | [BMK] | 03.2005-05.2006 |
AUDI | A6 3.0 TDi Quattro | [BNG] | 03.2005-08.2011 |
AUDI | A6 3.0 TDi Quattro | [CDYB] | 03.2005-08.2011 |
AUDI | A6 Allroad 2.7 TDi Quattro | [BPP] | 03.2006-10.2008 |
AUDI | A6 Allroad 2.7 TDi Quattro | [BSG] | 05.2006-08.2011 |
AUDI | A6 Allroad 2.7 TDi Quattro | [CAND] | 05.2006-08.2011 |
AUDI | A6 Allroad 3.0 TDi Quattro | [ASB] | 05.2006-10.2008 |
AUDI | A6 Allroad 3.0 TDi Quattro | [BNG] | 05.2006-08.2011 |
AUDI | A6 Allroad 3.0 TDi Quattro | [CDYB] | 05.2006-08.2011 |
AUDI | A8 3.0 TDi Quattro | [ASB] | 08.2003-07.2010 |
AUDI | A8 3.0 TDi Quattro | [BNG] | 11.2003-07.2010 |
AUDI | Q7 3.0 TDi Quattro | [BUG] | 03.2006-05.2008 |
AUDI | Q7 3.0 TDi Quattro | [BUN] | 03.2006-05.2010 |
AUDI | Q7 3.0 TDi Quattro | [CASA] | 11.2007-08.2015 |
AUDI | Q7 3.0 TDi Quattro | [CASB] | 03.2006-05.2010 |
AUDI | Q7 3.0 TDi Quattro | [CCMA] | 11.2007-08.2015 |
AUDI | Q7 3.0 TDi Quattro | [CJGA] | 11.2007-08.2015 |
AUDI | Q7 3.0 TDi Quattro | [CNRB] | 11.2007-08.2015 |
AUDI | Q7 4.2 TDi Quattro | [BTR] | 03.2007-06.2009 |
VW | Touareg 3.0 TDi | [BUN] | 04.2006-05.2010 |
VW | Touareg 3.0 TDi | [CASB] | 04.2006-05.2010 |
VW | Touareg 3.0 V6 TDi | [BKS] | 11.2004-05.2010 |
VW | Touareg 3.0 V6 TDi | [CASA] | 11.2007-05.2010 |
VW | Touareg 3.0 V6 TDi | [CASC] | 11.2007-05.2010 |
VW | Touareg 3.0 V6 TDi | [CATA] | 11.2004-05.2010 |
Reference Information
2015294 059903015R 11.1937M ALTL285 4651 205.523.180 9213002 VAL439527 2542784C 2542784B DRA0144 AEK2364 2542784 CAL15294OS 2542784A 1254 28-4870 944390903790 TG17C020 TG17C022 CAL15294GS CA1937IR 20877N-OE AX 23364R 210551 210831 89213002 301937RI 06C903016J 114408 437507 439527 23364N RNLTG17C020 LRA2364 RAA11255 6.3170.9 0986080090 059903017k ALB1937 CAL15294AS 0121715020 ALT14164 CAL15294 CAL15294ES 57210 LRA02364 301937RIV ALV1937 A3160 ALT172940 CAL15294RS EAA-221182 059903017KVideo/Publications
0121715020 059903015R 059903017K 059903017k 06C903016J 0986080090 11.1937M 114408 2015294 205.523.180 20877N-OE 210831 23364N 23364R 2542784 2542784A 2542784B 2542784C 28-4870 301937RI 301937RIV 437507 439527 4651 57210 6.3170.9 89213002 944390903790 A3160 AEK2364 ALB1937 ALT14164 ALT172940 ALTL285 ALV1937 AX 1254 CA1937IR CAL15294 CAL15294AS CAL15294ES CAL15294GS CAL15294OS CAL15294RS DRA0144 EAA-221182 LRA02364 LRA2364 RAA11255 RNLTG17C020 TG17C022 VAL439527 210551View your shopping basket or Browse other items in Alternators.
