Associated Numbers
0986CN0924 Bosch ruil AAM-C6034 0986CR0924 0986UR0924 2011354 Ford show 21059 Lester 2161084 2188081 2451723 288522 Elstock 40516 CEVAM 440810 Valeo 443011 595946165 PSH 717619 #160 A717619 A717619A 931971 EDR AL2401N (USA) AL2401X DRA1971 Remy GK2T10300AC GK2T10300AD GK2T10300AE GK2T10300AF LRA04413 Lucas TG15C206 TG15C255 TG15C255SEL +line GK2T-10300-AD GK2T-10300-AE MFR Series - Family Type AS7BP AAM-c6034 726564 RNLTG15C255 RNL S32000069 Herth Buss TG15C285 agv-c6034 47-570Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 165 A |
| Bottom Mounting Foot Width (B) | 21 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.5 mm |
| Diameter (D.4) | M10x1.5 mm |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 34 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 55 mm |
| Pad mount thickness (E.2) | 55 mm |
| Plug Code | PL_2305 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 48 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Ka 1.3 i | [A9A] | 08.2002-11.2008 |
| FORD | Ka 1.3 i | [A9B] | 08.2002-11.2008 |
| FORD | Ka 1.3 i | [BAA] | 09.1996-11.2008 |
| FORD | Ka 1.3 i | [J4D] | 09.1996-11.2008 |
| FORD | Ka 1.3 i | [J4K] | 09.1996-11.2008 |
| FORD | Ka 1.3 i | [J4M] | 09.1996-11.2008 |
| FORD | Ka 1.3 i | [J4N] | 09.1996-11.2008 |
| FORD | Ka 1.3 i | [J4P] | 09.1996-11.2008 |
| FORD | Ka 1.3 i | [J4S] | 09.1996-11.2008 |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BJFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BJFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BKFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BKFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BLFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [BLFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLF6] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YLFS] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMF6] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YMFS] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNF6] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNFA] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNFB] | 01.2015- |
| FORD | Tourneo Custom V362 2.0 EcoBlue | [YNFS] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BJFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BJFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BKFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BKFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BLFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [BLFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLF6] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YLFS] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMF6] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YMFS] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNF6] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNFA] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNFB] | 01.2015- |
| FORD | Transit Custom V362 2.0 EcoBlue | [YNFS] | 01.2015- |
| FORD | Transit V363 2.0 EcoBlue | [BJFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BJFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BKFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BKFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BLFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [BLFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLF6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YLFS] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMF6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YMFS] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNF6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNFA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNFB] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue | [YNFS] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [BKRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [BLRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YMR6] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YMRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YNR6] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue 4x4 | [YNRA] | 01.2017- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BJRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BKRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BLHA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [BLRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YLR6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YLRA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YMHA] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YMR6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | [YNR6] | 01.2016- |
| FORD | Transit V363 2.0 EcoBlue RWD | 01.2016- |
Reference Information
UD90769A 20179180OE 21059-OS TG15C206 209588 VAL443011 2188081 ALV3467 2161084 ALT170810 2015081.1 2011354 TG15C255 555231RIV 595.946.165.500 595.946.165.000 40516 LRA4413 GK2T-10300-AE CAL15081GS DRA1971 GK2T-10300-AC GK2T-10300-AD LRA04413 28-8522Video/Publications
2011354 2015081.1 20179180OE 209588 21059-OS 2161084 2188081 28-8522 40516 555231RIV 595.946.165.000 595.946.165.500 ALT170810 ALV3467 CAL15081GS DRA1971 GK2T-10300-AC GK2T-10300-AD GK2T-10300-AE LRA04413 LRA4413 TG15C206 TG15C255 UD90769A VAL443011View your shopping basket or Browse other items in Alternators.
