Associated Numbers
228000-4553 References: J&N 410-22009 JANNCO 410-22009R 410-52038R Denso 228000-455 228000-4550 228000-4551 228000-4552 Lester 18415 PIC Picture ID 190-493 Sea-Doo 278-000-484 278-000-485 278-001-300 278-001-935 Wilson 71-29-18415 91-29-5354 Substitutes: 410-52038 smx072 111915 Cargo 12090293 EuroTec 22147 Lucas 228000455 2280004550 show 2280004553 278000484 278000485 278001300 278001935 400061093 PSHSpecifications
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | M8x1.25 mm |
| Kilowatt | 0.6 kW |
| Length (L.1) | 203 mm |
| Mount Hole Center - Center (O.1) | 54 mm |
| Mount Hole Center - Center (O.2) | 77.5 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.3) | 10 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 25 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 60 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ROTAX MARINE - BRP | 587 Rotax Engine 2 Stroke | 581c | 1995, 1996 |
| ROTAX MARINE - BRP | 587 Rotax Engine, 2 Stroke | 581cc, 581cc | 1995, 1996 |
| ROTAX MARINE - BRP | 657 Rotax Engine 2 Stroke | 650c | 1995, 1996 |
| ROTAX MARINE - BRP | 657 Rotax Engine, 2 Stroke | 650cc, 650cc | 1995, 1996 |
| ROTAX MARINE - BRP | 717 Rotax Engine 2 Stroke | 718c | 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005 |
| ROTAX MARINE - BRP | 717 Rotax Engine, 2 Stroke | 718cc, 718cc | 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005 |
| SEA-DOO | Challenger 1800 Jet Boat Twin Eng | 1998 | |
| SEA-DOO | Explorer | 1995, 1996, 1997 | |
| SEA-DOO | Explorer Jet Boat | 720cc | 1995, 1996, 1997 |
| SEA-DOO | GS | 720cc | 1998, 1999, 2000, 2001 |
| SEA-DOO | GSI | 720cc | 1997 |
| SEA-DOO | GTI | 1494cc | 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004 |
| SEA-DOO | GTI | 720cc | 2004, 2005 |
| SEA-DOO | GTI LE | 720cc | 2004 |
| SEA-DOO | GTS | 580cc | 1995, 1996 |
| SEA-DOO | GTS | 720cc | 1998, 1999, 2000, 2001 |
| SEA-DOO | GTX | 650cc | 1995 |
| SEA-DOO | HX | 720cc | 1995, 1996, 1997 |
| SEA-DOO | SP | 580cc | 1995, 1996 |
| SEA-DOO | SP | 720cc | 1997 |
| SEA-DOO | Speedster | 1995, 1996, 1997 | |
| SEA-DOO | Speedster SK | 1999 | |
| SEA-DOO | SPI | 580cc | 1995, 1996 |
| SEA-DOO | Sportster | 1995, 1996, 1997, 1998, 1999 | |
| SEA-DOO | SPX | 650cc | 1995 |
| SEA-DOO | SPX | 720cc | 1996 |
| SEA-DOO | SPX | 800cc | 1997 |
| SEA-DOO | XP | 720cc | 1995 |
Reference Information
228000-4551 228000-4550 228000-4552 228000-4553
