Brand new OEM SEG / BOSCH
PREMIUM LINE
BOSCH
Bosch
Price:
NZ$ 959.96 including GST
NZ$ 834.75 excluding GST
or four payments of $239.99
with
Learn More
each
A0786S
AGB-C6047
1
Associated Numbers
0125811013 Bosch show
0125811014 Bosch show
0125811083 Bosch show
0125811084 Bosch show
12090708 EuroTec
1768612 Ford
1874991 Ford
2193152102 DRI
286760 Elstock
32811013 Herth Buss
4100 CEVAM
57517 EAI
595903210 PSH
BK2T10300DA Ford
BK2T10300DB Ford
DRA1722 Remy
LRA03699 Lucas
Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 56 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 13.5 mm |
| Length (L.1) | 194 mm |
| Mount Inside Length or Pad Mount C-C (C) | 74 mm |
| OEM Product | Yes |
| Pad mount thickness (E.1) | 97 mm |
| Pad mount thickness (E.2) | 97 mm |
| Plug Code | PL_9105 |
| Product Line | Premium Line |
| Product Type | Brand new |
| Pulley Grooves | 7 qty |
| Pulley Outside Diameter (O.D.1) | 52 mm |
| Pulley to Mount Distance (A) | 83.5 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LAND ROVER | Discovery 4.0 V8 4x4 | [35D] | 01.1998-12.2004 |
| LAND ROVER | Discovery 4.0 V8 4x4 | [56D] | 01.1998-12.2004 |
| LAND ROVER | Discovery 4.0 V8 4x4 | [94D] | 01.1998-12.2004 |
| LAND ROVER | Range Rover 3.9 4x4 | [42D] | 01.1994-12.2002 |
| LAND ROVER | Range Rover 4.0 4x4 | [42D] | 01.1995-12.2002 |
| LAND ROVER | Range Rover 4.6 4x4 | [46D] | 01.1995-12.2002 |
| LAND ROVER | Range Rover 4.6 4x4 | [60D] | 01.1998-12.2002 |
Reference Information
0125811084 UD18525A 0125811083 LRA3699 1874991 UD13013A 89215909 1768612 20786-OS AEG1356 DA2832 DRA1722 BOS0125811083 0125811013 0125811014 554633RIR ALT125390 4100 595.903.210 209397 LRA03699 ALTJ131 2010539.1 554633RIB CAL10539GS CGB-86760 20101935OE 28-6760 BK2T-10300-DB 57517 BK2T-10300-DAVideo/Publications
0125811013 0125811014 0125811083 0125811084 1768612 1874991 20101935OE 2010539.1 20786-OS 209397 28-6760 4100 554633RIB 554633RIR 57517 595.903.210 89215909 AEG1356 ALT125390 ALTJ131 BK2T-10300-DA BK2T-10300-DB BOS0125811083 CAL10539GS CGB-86760 DA2832 DRA1722 LRA03699 LRA3699 UD13013A UD18525AView your shopping basket or Browse other items in Alternators.
