Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 285.56 including GST
NZ$ 248.31 excluding GST
or four payments of $71.39
with
Learn More
each
SGV-C11001
S1268S
1
Information
8000748Specifications
| Kilowatt | 0.9 kW |
| Length (L.1) | 175 mm |
| Mount Hole Center - Center (O.1) | 94 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 14 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | i20 1.0 T-GDi | [G3LC] | 01.2016- |
| HYUNDAI | i20 1.4 | [G4LC] | 05.2015- |
| HYUNDAI | i20 1.4 | [G4LC] | 11.2014- |
| HYUNDAI | i20 Active 1.0 T-GDi | [G3LC] | 09.2015- |
| HYUNDAI | i20 Active 1.4 | [G4LC] | 09.2015- |
Reference Information
36100-03851 6046123.1 8000748 LRS03909 150.939.112.038 88215175 MAV481230 36100-04900 CST46123GS LRS3909 150.939.112.030 150.939.112.360 UD90557S 3738 20460321OE DRS1125 25-5072 256423D 8000798 3610003853Video/Publications
