Remanufactured AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 243.28 including GST
NZ$ 211.55 excluding GST
or four payments of $60.82
with
Learn More
each
S0195SR
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 236 mm |
| Mount Hole Center - Center (O.1) | 83 mm |
| Mount Hole Center - Center (O.2) | 116 mm |
| Mount Hole Center - Center (O.3) | 83 mm |
| Mount Hole Diameter (C.1) | 8.5 mm |
| Mount Hole Diameter (C.2) | 8.5 mm |
| Mount Hole Diameter (C.3) | 8.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 9 mm |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 145 1.9 JTD | [AR32302] | 02.1999-01.2001 |
| ALFA ROMEO | 147 1.9 JTD | [937A2.000] | 11.2000-05.2002 |
| ALFA ROMEO | 147 1.9 JTD 16V | [192A5.000] | 04.2005- |
| ALFA ROMEO | 147 1.9 JTD 16V | [937A4.000] | 04.2005- |
| ALFA ROMEO | 147 1.9 JTDM | [937A6.000] | 06.2008- |
| ALFA ROMEO | 147 1.9 JTDM 16V | [937A5.000] | 07.2005- |
| ALFA ROMEO | 156 1.9 JTD | [937A2.000] | 05.2001-05.2006 |
| ALFA ROMEO | 156 1.9 JTD | [AR32302] | 09.1997-10.2000 |
| ALFA ROMEO | 156 1.9 JTD | [AR37101] | 10.2000-12.2001 |
| ALFA ROMEO | 159 1.9 JTDM 16V | [937A8.000] | 09.2005- |
| ALFA ROMEO | 159 1.9 JTDM 16V | [939A2.000] | 09.2005- |
| ALFA ROMEO | 159 1.9 JTDM 16V | [939A8.000] | 09.2005- |
| ALFA ROMEO | 159 1.9 JTDM 8V | [939A7.000] | 09.2005- |
| FIAT | Brava 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Brava 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Brava 1.9 TD | [182A7.000] | 03.1996-10.2001 |
| FIAT | Brava 1.9 TD | [182A8.000] | 03.1996-10.2001 |
| FIAT | Bravo 1.6 Multijet | [198A2.000] | 03.2008- |
| FIAT | Bravo 1.9 Diesel Multijet | [937A5.000] | 04.2007- |
| FIAT | Bravo 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Bravo 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Bravo 1.9 TD | [182A7.000] | 03.1996-10.2001 |
| FIAT | Croma 1.9 Diesel Multijet | [939A2.000] | 06.2005- |
| FIAT | Doblo 1.9 JTD | [182B9.000] | 10.2001- |
| FIAT | Doblo 1.9 JTD | [223A7.000] | 10.2001-09.2005 |
| FIAT | Doblo 1.9 JTD | [223B1.000] | 10.2001-09.2005 |
| FIAT | Doblo 1.9 JTD | [223B2.000] | 10.2001- |
| FIAT | Grande Punto 1.9 Diesel Multijet | [199A5.000] | 10.2005- |
| FIAT | Marea 1.9 JTD | [182B4.000] | 04.1999-01.2001 |
| FIAT | Marea 1.9 JTD | [186A6.000] | 01.2001- |
| FIAT | Marea 1.9 TD | [182A7.000] | 09.1996- |
| FIAT | Marea 1.9 TD | [182A8.000] | 09.1996- |
| FIAT | Marea 1.9 TDi | [182A7.000] | 09.1996- |
| FIAT | Marengo 1.9 JTD | [182B4.000] | 03.1999-09.2002 |
| FIAT | Marengo 1.9 JTD | [186A6.000] | 08.2000-09.2002 |
| FIAT | Marengo 1.9 TD | [182A7.000] | 01.1997-02.1999 |
| FIAT | Marengo 1.9 TD | [182A8.000] | 03.1999-09.2002 |
| FIAT | Multipla 1.9 JTD | [182B4.000] | 04.1999- |
| FIAT | Multipla 1.9 JTD | [186A6.000] | 03.2001- |
| FIAT | Multipla 1.9 JTD | [186A8.000] | 07.2002- |
| FIAT | Punto 1.9 JTD | [188A2.000] | 09.1999- |
| FIAT | Punto 1.9 JTD | [188A7.000] | 06.2001-06.2003 |
| FIAT | Stilo 1.9 Diesel | [192B5.000] | 09.2004- |
| FIAT | Stilo 1.9 Diesel Multijet | [192A8.000] | 09.2005- |
| FIAT | Stilo 1.9 Diesel Multijet | [192A9.000] | 09.2005- |
| FIAT | Stilo 1.9 Diesel Multijet | [937A5.000] | 09.2005- |
| FIAT | Stilo 1.9 JTD | [192A1.000] | 10.2001- |
| FIAT | Stilo 1.9 JTD | [192A3.000] | 10.2001- |
| FIAT | Stilo 1.9 JTD | [192B5.000] | 09.2004- |
| FIAT | Stilo 1.9 JTD | [937A7.000] | 01.2003- |
| FIAT | Strada 1.9 JTD | [188A2.000] | 04.2003- |
| LANCIA | Lybra 1.9 JTD | [937A2.000] | 05.2001- |
| LANCIA | Lybra 1.9 JTD | [AR32302] | 07.1999-09.2000 |
| LANCIA | Lybra 1.9 JTD | [AR37101] | 09.2000- |
| LANCIA | Lybra 1.9 JTD SW | [AR37101] | 09.2000- |
| LANCIA | Lybra 2.4 JTD | [839A5.000] | 10.1999-09.2000 |
| LANCIA | Lybra 2.4 JTD | [839A6.000] | 09.2000-05.2002 |
| LANCIA | Lybra 2.4 JTD | [AR32501] | 10.1999-09.2000 |
| LANCIA | Lybra 2.4 JTD SW | [839A6.000] | 09.2000-05.2002 |
| LANCIA | Thesis 2.4 JTD | [841C.000] | 04.2002- |
Reference Information
500.579.093.215 6010287.0 6010287.1 MRS18900 5010034 31100-H79J0-0000 PRSS207 6202074 063114008010 CST10287OS 0001109253 201162 S0195 51832954 51832953 STA0007R CST10287GS 943210451010 60814911 71721774 71722349 CGB-53002 063521092680 NPANSM1028 AZE2111 101045 20401492BN 71789267 31100-79J00 46748351 42018900 IS0997 063721045010 944280177900 0001115025 32669N 71721240 0001115021 20404111OE 0001109268 500.579.093.210 0001109269 STX200037 GS109030B-R 31100H79J00-000 944280189000 S12BH0020A2 31100-79J00-000 46473784 201068 311348 STRL008B 458212 STRL008 8EA737294-001 20401782RE 101045B 55585237 20510199 55195211 6030111.2 6030111.1 DENDSN3018 6030111.0 46478945 101045M CST10294OS STX200011 331197 93951832953 20401782BN 0986017790 MSN610 CST10294GS 71746669 ANM15534X 3110079J00000 063521082390 063113002010 3680 500.579.093.018 MS373 331458 51782321 46451895 20404111RC 25-3002 458550 LRT199 063721264010 0001109336 STM1035 0001109337 726043 CST10287AS MSRC1045 88212453 46463250 55192482 93955195029 20401492OE 8EA011610-011 72736001 46430784 CST30111RS 551952110 STR1945 MQS1045 STRS207 71723345 71723462 CST30111AS 20404111BN S12BH0789A2 113297 500.579.093.770 CST10294AS 500.579.093.010 46817002 STX200037R 71782384 20401492RE 71782386 CST30111GS DRS3314X 46800159 55195029 0001109270 STX200200 0001109030 STB1045 SG0099 11.130.997 71792037 STX200200R 0001109438 GS109030-A 20401782OE 6010294.4 4765911 71782379 46823543 PRSL008 LRT00199 MAV122940 6010294.1 004765911 6010294.0 ASM1028 RAS34425 220720 60816083 11932 943114008010 MRS17790 MSR610 1202282 STX200294 0001109045 STR52046 113430 63113002 STX200011R STR79103 55832954Video/Publications
