Associated Numbers
0986014980 Bosch ruil
0986024330 Bosch ruil
0986UR1341 Bosch ruil
0986UR1346 Bosch ruil
0K24018400 Kia
0K24118400A Kia
0K90018400 Kia
11040671 EuroTec
11124482 Mazda
112215 Cargo
113138 Cargo
11704 Stemot
140012083 PSH
16922 Lester
1EM0088 Mando
2280003380 Denso
250395 Elstock
251376 Elstock
324020082 DRI
324029082 DRI
455506 Valeo
8052303 Friesen
8052309 Friesen
8052310 Friesen
8052313 Friesen
8052327 Friesen
8052335F Friesen
8EA726421001 Hella
8EA726550001 Hella
8EA737693001 Hella
91273123 Wilson
91273181 Wilson
913511 EDR
913724 EDR
914991 EDR
AA30G18400 Mazda
AES8186 Auto Electro
AMS193 ATK
B31518400A Mazda
B50518400AT Mazda
B61R18400 Mazda
B61R18400A Mazda
B61R18400A9R Mazda
B63018400AT Mazda
B67618400AT Mazda
BPE918400 Mazda
DRS3724 Remy
DRS4991 Remy
E30118400AT Mazda
E35618400AT Mazda
F24018400AT Mazda
F60118400AT Mazda
F60118400B Mazda
F80218400AT Mazda
F80618400 Mazda
F85018400A Mazda
F85018400C Mazda
F85018400D Mazda
F8B118400AT Mazda
F8B118400B Mazda
FE0518400AT Mazda
FE5018400AT Mazda
FE5018400D Mazda
J5213035 Herth Buss
J5213039 Nipparts
LRS00624 Lucas
LRS00627 Lucas
LRS00688 Lucas
LRS00886 Lucas
LRS02055 Lucas
LRS627 Lucas
LRS688 Lucas
LRS886 Lucas
M001T78181 Mitsubishi show
M003T32282 Mitsubishi
M003T48181 Mitsubishi show
M1T78181 Mitsubishi show
M3T32282 Mitsubishi
M3T48181 Mitsubishi show
MSR1012 Magneti Marelli
MSR1114 Magneti Marelli
MSR925 Magneti Marelli
OK24018400 Kia
OK24118400A Kia
PE24731100 Kia
S27260 Hitachi
S8734 Dixie
SP1135 Spidan
SP1203 Spidan
SP4448 Spidan
SP4609 Spidan
SR4215X Bosch (USA)
SR4220X Bosch (USA)
STR3067 Unipoint
TRS194 TWA
BOSCH SR4220X
LESTER 17689
MAZDA BPE9-18-400
MITSUBISHI M1T78181
SR4220X
Bosch Service Europe 0-986-UR1-346
DENSO Auto Parts 280-4242
IAT S17689
Lester 17689
Lucas (Europe) LRS886
Lucas Reman S9434
Mazda BPE9-18-400, BPE9-18-400R
Mitsubishi M1T78181
NAPA 44-6640
NSA STR-3067
PIC 103-277
Remy 17259
Unipoint STR-3067
SRJ517
ACDelco 323-1093
Bosch Reman SR4215X
Bosch Service Europe 0-986-014-351, 0-986-UR1-341
Delco Europe DRS0030, DRS0131
Delco Reman Europe DRS3724
Delco-Remy 19011961
DENSO Auto Parts 280-4160
Friesen 24-52.310, 8052335
HC Parts JS1146
Hella 8EA737693-001
IAT S17662
Lester 17662
Lucas (Europe) LRS00886, LRS886
Lucas Reman S9425
Mazda B61P-18-400, B61R-18-400, B61R-18-400A, B61R-18-400R, B61R-18-400R00, BPE8-18-400
Mitsubishi M003T39981, M003T48181, M003T48181MU, M003T48181ZC, M3T39981, M3T48181, M3T48181ZC
NAPA 44-6254
PIC 103-101C, 103-138
Quinton Hazell 8052335
Remy 17193
Unipoint F042S0H038
Valeo Short VS373
ARROWHEAD BSR4215X
BOSCH SR4215X
LESTER 17662
LUCAS ELECTRIC S9425
MAZDA B61P18-400, B61R18-400, B61R18-400A, B61R18-400R, B61R18-400R00
MITSUBISHI M3T39981, M3T48181
VALEO VS373
Specifications
| Diameter (D.1) | M10x1.25 mm |
| Diameter (D.2) | M10x1.25 mm |
| Length (L.1) | 200 mm |
| Mount Hole Center - Center (O.1) | 68 mm |
| Mount Hole Center - Center (O.2) | 85 mm |
| Mount Hole Center - Center (O.3) | 112 mm |
| Mount Hole Diameter (C.3) | 11.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 8 qty |
| Pinion at Rest (B) | 18 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| EUNOS | MX5 | 1989-1993 | |
| MAZDA | MX5 | 1989-1993 |
Reference Information
M003T39981, M003T48181, M003T48181MU, M003T48181ZC, M3T39981, M3T48181, M3T48181ZC
