Associated Numbers
CA52433 ACE
CA5243307 ACE
10463375 DELCO REMY
10463624 DELCO REMY
10480157 DELCO REMY
1101644 DELCO REMY
3211086 DELCO REMY
3342403 DELCO REMY
3342461 DELCO REMY
8114 LESTER
81143 LESTER
8217 LESTER
82173 LESTER
LRA01806 LUCAS
134531 NAPA / RAYLOC
90014240 WILSON
0986CR0589 Bosch ruil
0986UR0589 Bosch ruil
10463375 Remy
10463624 Remy
10480157 Remy
1101644 Remy
1101644Y Remy
111854 Cargo
2405137 PIC
2405138 PIC
283622 Elstock
3211086 Remy
5281441052 DRI
66143 NAPA
81143 Lester
82173 Lester
835040105 PSH
90014240 Wilson
A1403 Dixie
AL8597X Bosch (USA)
ALT1309 Unipoint
ALT1309A Unipoint
ALT1338A Unipoint
LRA01806 Lucas
LRA1806 Lucas
90014668 WILSON
AC DELCO TOOLS 321-1004, 321-1086, 334-2403, 334-2461
BOSCH AL8597X
DELCO 10463375, 10463624, 10480157, 1101644, 321-1004, 321-1086, 334-2403, 334-2461
DENSO 210-5126
J&N ELECTRICAL PRODUCTS 400-12233
LESTER 8114, 8114-3, 8217, 8217-3
LUCAS ELECTRIC LRA01806
321-1004, 334-2403, 334-2403A, 335-1029
Ace Electric CA8114-3N, CA8217-3N
Bosch Newman AL8597N
Bosch Reman AL8597X
Bosch Service Europe 0-986-UR0-589
Canadian Tire 195457
Delco-Remy 10463375, 1101644
DENSO Auto Parts 210-5126
IAT A8114-3
Lester 8114-3
Lucas (Europe) LRA01806, LRA1806
Lucas Reman A1843-3
Minnpar 47-1853
Model Number CS130
NAPA 13-4531, 13-4549, 213-4531, 213-4549
NAPA New 1N-4549, 1N4531
NSA ALT-1309A
PIC 240-5137
Road Force RF569047815, RF59907805
Unipoint ALT-1309, ALT-1338A
Specifications
| Amp | 105 A |
| Bottom Mounting Foot Width (B) | 12.5 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Length (L.1) | 175 mm |
| Mount Inside Length or Pad Mount C-C (C) | 79 mm |
| OEM Product | No |
| Plug Code | PL_4200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | CAMARO | 3400cc, 3.4L/207CI V6 | 1993, 1994, 1995 |
| CHEVROLET | CAMARO | 3.4L(207) V | 1993, 1995 |
| CHEVROLET | CAMARO | 3.4L(207) V | 1994 |
| CHEVROLET | CAMARO BASE | 3400cc, 3.4L/207CI V6 | 1993, 1994, 1995 |
| PONTIAC | FIREBIRD | 3400cc, 3.4L/207CI V6 | 1993, 1994, 1995 |
| PONTIAC | FIREBIRD | 3.4L(207) V | 1993, 1995 |
| PONTIAC | FIREBIRD | 3.4L(207) V | 1994 |
| PONTIAC | FIREBIRD BASE | 3400cc, 3.4L/207CI V6 | 1993, 1994, 1995 |
Reference Information
10463375, 1101644
