Specifications
| Inside Diameter (I.D.1) | 12 mm |
| Length (L.1) | 51.5 mm |
| Length (L.2) | 17.3 mm |
| No./Splines | 10 qty |
| No./Teeth | 8 qty |
| OEM Product | No |
| Outside Diameter (O.D.1) | 46 mm |
| Outside Diameter (O.D.2) | 34 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Type | Drive |
| Unit Type | MADNO |
Reference Information
UD49971SDVideo/Publications
MG117559 TM000A07101 SD9283S S9367SView your shopping basket or Browse other items in Drives, Pinions and Clutches.
