Brand new OEM SEG Starter motor
PREMIUM LINE
SEG
BOSCH
Price:
NZ$ 557.28 including GST
NZ$ 484.59 excluding GST
or four payments of $139.32
with
Learn More
each
S0611(SEG)
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
0001138017Specifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 229 mm |
| Mount Hole Center - Center (O.1) | 99 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 22 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 77 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | i30 1.4 | [G4FA] | 05.2013-12.2014 |
| HYUNDAI | i30 1.4 | [G4FA] | 10.2007-06.2012 |
| HYUNDAI | i30 1.4 | [G4FA] | 10.2007-11.2011 |
| HYUNDAI | i30 1.4 | [G4FA] | 11.2009-06.2012 |
| HYUNDAI | i30 1.4 | [G4FA] | 12.2011-12.2015 |
| HYUNDAI | i30 1.6 | [G4FC] | 01.2012-12.2016 |
| HYUNDAI | i30 1.6 | [G4FC] | 02.2008-06.2012 |
| HYUNDAI | i30 1.6 | [G4FC] | 02.2008-11.2011 |
| HYUNDAI | i30 1.6 | [G4FC] | 06.2012- |
| HYUNDAI | i30 1.6 | [G4FC] | 10.2007-11.2011 |
| HYUNDAI | i30 1.6 | [G4FC] | 12.2011-12.2015 |
| HYUNDAI | i30 1.6 | [G4FD] | 06.2012-12.2015 |
| HYUNDAI | i30 1.6 | [G4FG] | 01.2012-12.2016 |
| HYUNDAI | i30 1.6 | [G4FG] | 06.2012- |
| HYUNDAI | i30 1.6 GDi | [G4FD] | 05.2013- |
| HYUNDAI | i30 1.6 GDi | [G4FD] | 06.2012- |
| HYUNDAI | i30 1.6 GDi | [G4FD] | 12.2011-12.2016 |
| HYUNDAI | i30 1.6 MPi | [G4FC] | 05.2013- |
| HYUNDAI | i30 1.6 T-GDi | [G4FJ] | 01.2015- |
| HYUNDAI | i40 1.6 GDi | [G4FD] | 03.2012-05.2019 |
| HYUNDAI | i40 CW 1.6 GDi | [G4FD] | 07.2011-05.2019 |
| HYUNDAI | ix20 1.4 | [G4FA] | 11.2010-07.2019 |
| HYUNDAI | ix20 1.6 | [G4FC] | 11.2010-07.2019 |
| HYUNDAI | ix35 1.6 | [G4FD] | 11.2010-12.2015 |
| HYUNDAI | Tucson 1.6 GDi | [G4FD] | 06.2015-09.2020 |
| HYUNDAI | Veloster 1.6 GDi | [G4FD] | 03.2011-12.2017 |
| HYUNDAI | Veloster 1.6 MPi | [G4FC] | 04.2011-12.2017 |
| HYUNDAI | Veloster 1.6 MPi | [G4FG] | 04.2011-12.2017 |
| KIA | Ceed 1.4 | [G4FA] | 12.2006-12.2012 |
| KIA | Ceed 1.4 CVVT | [G4FA] | 05.2012-07.2018 |
| KIA | Ceed 1.4 CVVT | [G4FA] | 08.2009-12.2012 |
| KIA | Ceed 1.4 CVVT | [G4FA] | 09.2012-07.2015 |
| KIA | Ceed 1.6 | [G4FC] | 02.2008-12.2012 |
| KIA | Ceed 1.6 | [G4FC] | 09.2007-12.2012 |
| KIA | Ceed 1.6 | [G4FC] | 12.2006-12.2012 |
| KIA | Ceed 1.6 CVVT | [G4FC] | 10.2010-12.2012 |
| KIA | Ceed 1.6 GDi | [G4FD] | 05.2012-07.2018 |
| KIA | Ceed 1.6 GDi | [G4FD] | 09.2012-07.2018 |
| KIA | Ceed SW 1.4 | [G4FA] | 09.2007-12.2012 |
| KIA | Ceed SW 1.4 | [G4FA] | 10.2010-12.2012 |
| KIA | Ceed SW 1.4 CVVT | [G4FA] | 07.2009-12.2012 |
| KIA | Ceed SW 1.6 | [G4FC] | 09.2007-11.2012 |
| KIA | Ceed SW 1.6 | [G4FC] | 09.2007-12.2012 |
| KIA | Ceed SW 1.6 CVVT | [G4FC] | 06.2009-12.2012 |
| KIA | Pro Ceed 1.4 | [G4FA] | 02.2008-09.2012 |
| KIA | Pro Ceed 1.4 CVVT | [G4FA] | 03.2013-07.2015 |
| KIA | Pro Ceed 1.4 CVVT | [G4FA] | 06.2010-09.2012 |
| KIA | Pro Ceed 1.4 MPi | [G4LC] | 07.2013-07.2018 |
| KIA | Pro Ceed 1.6 | [G4FC] | 02.2008-09.2012 |
| KIA | Pro Ceed 1.6 CVVT | [G4FC] | 10.2010-02.2013 |
| KIA | Pro Ceed 1.6 GDi | [G4FD] | 03.2013-07.2018 |
| KIA | Rio 1.4 CVVT | [G4FA] | 09.2011-12.2017 |
| KIA | Rio 1.4 CVVT | [G4FA] | 10.2011-12.2017 |
| KIA | Soul 1.6 | [G4FC] | 09.2009-12.2014 |
| KIA | Soul 1.6 CVVT | [G4FC] | 02.2009-12.2011 |
| KIA | Soul 1.6 GDi | [G4FD] | 06.2011-12.2014 |
| KIA | Soul 1.6 LPG | [G4FC] | 02.2009-12.2011 |
| KIA | Sportage 1.6 GDi | [G4FD] | 06.2010-12.2015 |
| KIA | Sportage 1.6 GDi | [G4FD] | 09.2015-09.2022 |
| KIA | Venga 1.4 CVVT | [G4FA] | 02.2010-03.2019 |
| KIA | Venga 1.4 LPG | [G4FA] | 02.2010-03.2019 |
| KIA | Venga 1.6 CVVT | [G4FC] | 02.2010-03.2019 |
Reference Information
11040794 LRS2458 150.578.092.018 150.578.092.211 150.578.092.010 8550504907 BOS0001138017 3112047 324066092 3112046 CST10510GS STM1396 256581B 220546A 25-4130 458837 438406 20401015BN UD03985(SEG)S 220546 150.578.092.280 STR50687 STRS403 1986S00831 19158N 0986025140 88214305 SBO510A 9868 S12BH0327A2 WOOSTR50687 20401015OE 6010510.1 6010510.0 SEG0001138018 12173 F032114887 114887 173ST21 HY9015 DRS0312 336056 8EA011611-571 QRS2537 0001138017-R 13542 5010406 438562 LRS02458 ST01645 CST10510AS 107447 0001138018 STX210227R J5210529 0001138017 A25140 256581 10010510AV A53-12-38017 10438665 M36100-2B300 36100-2B300 8550506297Video/Publications
