Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 317.00 including GST
NZ$ 275.65 excluding GST
or four payments of $79.25
with
Learn More
each
S6545S
No stock in NZ
No stock in NZ
Information
428000-1840Specifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 204 mm |
| Mount Hole Center - Center (O.1) | 123 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| OEM Product | No |
| Pinion at Rest (B) | 65 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 55 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | ES 250 2.5 | [2AR-FE] | 06.2012-06.2018 |
| LEXUS | ES 350 3.5 | [2GR-FE] | 06.2012-06.2018 |
| LEXUS | RX 300 3.0 | [1MZ-FE] | 05.2003-12.2008 |
| LEXUS | RX 330 3.3 | [3MZ-FE] | 04.2003-01.2006 |
| LEXUS | RX 330 3.3 AWD | [3MZ-FE] | 04.2003-12.2008 |
| LEXUS | RX 350 3.5 AWD | [2GR-FE] | 02.2006-12.2008 |
| LEXUS | RX 350 3.5 AWD | [2GR-FE] | 12.2008-08.2015 |
| LEXUS | RX 350 3.5 AWD | [2GR-FXE] | 12.2008-08.2015 |
| TOYOTA | Camry 2.0 | [1AZ-FE] | 08.2001-11.2009 |
| TOYOTA | Camry 2.4 | [1AZ-FE] | 08.2001-11.2006 |
| TOYOTA | Camry 2.4 | [1MZ-FE] | 08.2001-11.2006 |
| TOYOTA | Camry 2.4 | [2AZ-FE] | 01.2006-09.2011 |
| TOYOTA | Camry 3.0 | [2AZ-FE] | 11.2001-11.2006 |
| TOYOTA | Camry 3.5 | [2GR-FE] | 09.2006-12.2014 |
| TOYOTA | Camry 3.5 | [2GR-FE] | 09.2011-12.2017 |
| TOYOTA | Previa 2.4 | [2AZ-FE] | 10.2005- |
| TOYOTA | Rav 2.0 4WD | [1AZ-FE] | 02.2006-06.2013 |
| TOYOTA | Rav 2.4 | [2AZ-FE] | 11.2005-12.2013 |
| TOYOTA | Rav 2.5 4WD | [2AR-FE] | 12.2012- |
| TOYOTA | Rav 3.5 4WD | [2GR-FE] | 11.2005-12.2012 |
Reference Information
428000-7491 428000-7492 428000-7493 428000-7490 428000-5870 MAV423030 CST40303AS 428000-5871 25-4099 28100-28081 28100-28080 28100-28082 428000-7480 428000-7481 428000-7482 428000-7483 STR6758 0986026080 20432303BN 255502 428000-5900 428000-5904 LRS02427 428000-5903 428000-5902 428000-5901 228000-9903 228000-9904 STR6809 228000-9900 228000-9901 228000-9902 190.550.132.050 DENDSN1003 428000-5890 CST40327AS 190.550.132.058 28100-28062 S12DE0584A2 WG1920047 28100-28061 CST40303GS 28100-28060 428080-7493 190.574.132.050 DSN977 428000-5881 428000-5880 28100-OH060 428000-1840 428000-1841 190.574.132.058 STX200176R 28100-28070 428000-1842 28100-28072 428000-1843 28100-28071 190.574.132.260 428000-3090 428000-3091 428000-3092 28100-20020-84 28100-28041 28100-28040 28100-31100 28100-31101 28100-28042 28100-31102 20432303OE DSN1003 3322 428080-7504 20432723BN 28100-28052 28100-28051 28100-28053 6040327.0 28100-28050 28100-0P031 28100-0P032 WOOSTR70097 28100-0V012 28100-20022 MAV423030A STN0244 28100-20021 28100-20020 AC-CBS1519 UD102079S LRS2427 428000-7500 STX200176 428000-0150 428000-7501 428000-7502 STR70097 428000-0152 428000-0151 428000-0153 28100-0A011 28100-0A010 6040303.1 6040303.0 428000-7503 STR6293 STX200577Video/Publications
