Specifications
| Kilowatt | 1.6 kW |
| Length (L.1) | 215 mm |
| Mount Hole Center - Center (O.1) | 137 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 15 qty |
| OEM Product | No |
| Pinion at Rest (B) | 27 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ASTON MARTIN | Cygnet 1.3 | [1NR-FE] | 04.2011-10.2013 |
| TOYOTA | IQ 1.3 | [1NR-FE] | 01.2009-12.2015 |
Reference Information
88215157 LRS3959 428000-9010 10040506AV 6040506 428000-6580 S6546S 428000-9011 335255152 428000-8600 DSN1240 ST02084 28100-47162 UD19721S CST40506AS 3630 MAV425060A LRS03959 20432605BN 25-5121 28100-47161 28100-47160Video/Publications
