Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 376.65 including GST
NZ$ 327.52 excluding GST
or four payments of $94.16
with
Learn More
each
S6591S
No stock in NZ
No stock in NZ
Information
428000-9470Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 247 mm |
| Mount Hole Center - Center (O.1) | 69 mm |
| Mount Hole Center - Center (O.2) | 121 mm |
| Mount Hole Center - Center (O.3) | 94 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 27 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 84 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| IVECO | Daily 29L13 2.3 | [F1AE3481B] | 09.2011-02.2014 |
| IVECO | Daily 29S13 2.3 | [F1AE3481B] | 09.2011-02.2014 |
| IVECO | Daily 33S11 2.3 | [F1AFL411A] | 03.2014-07.2021 |
| IVECO | Daily 33S13 2.3 | [F1AFL411B] | 03.2014- |
| IVECO | Daily 33S15 2.3 | [F1AFL411C] | 03.2014- |
| IVECO | Daily 35C11 2.3 | [F1AFL411A] | 03.2014-07.2021 |
| IVECO | Daily 35C13 2.3 | [F1AE3481B] | 09.2011-02.2014 |
| IVECO | Daily 35C13 2.3 | [F1AFL411B] | 03.2014- |
| IVECO | Daily 35C15 2.3 | [F1AFL411C] | 03.2014- |
| IVECO | Daily 35S11 2.3 | [F1AFL411A] | 03.2014-07.2021 |
| IVECO | Daily 35S13 2.3 | [F1AE3481B] | 09.2011-02.2014 |
| IVECO | Daily 35S13 2.3 | [F1AFL411B] | 03.2014- |
| IVECO | Daily 35S15 2.3 | [F1AFL411C] | 03.2014- |
| IVECO | Daily 40C13 2.3 | [F1AE3481B] | 09.2011-02.2014 |
| IVECO | Daily 40S13 2.3 | [F1AE3481B] | 09.2011-02.2014 |
Reference Information
CST40438AS 3332 CST40438GS LRS04097 ST02214 318233112 11090470 428000-9470 10040438OV 31393N LRS4097 25-5260 500.408.113.260 UD102234S 255901 500.408.113.050Video/Publications
S6591SView your shopping basket or Browse other items in Starter Motors.
