Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 245.79 including GST
NZ$ 213.73 excluding GST
or four payments of $61.45
with
Learn More
each
S5599S
No stock in NZ
No stock in NZ
Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 174 mm |
| Mount Hole Center - Center (O.1) | 100 mm |
| Mount Hole Center - Center (O.2) | 37 mm |
| Mount Hole Center - Center (O.3) | 106 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| Mount Hole Diameter (C.3) | M10x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 16 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | 2 1.3 | [ZJ46] | 10.2007-06.2015 |
| MAZDA | 2 1.3 BiFuel | [ZJ-46] | 05.2011-11.2014 |
| MAZDA | 2 1.3 MZR | [ZJ46] | 01.2010-06.2015 |
| MAZDA | 2 1.3 MZR | [ZJ-VE] | 01.2010-06.2015 |
| MAZDA | 2 1.5 | [ZY66] | 07.2007-06.2015 |
| MAZDA | 2 1.5 | [ZY84] | 07.2007-06.2015 |
| MAZDA | 2 1.5 | [ZY-VE] | 10.2007-06.2015 |
| MAZDA | 2 1.5 MZR | [ZY05] | 06.2011-06.2015 |
| MAZDA | 2 1.5 MZR | [ZY66] | 06.2011-06.2015 |
| MAZDA | 3 1.6 | [Z6Y1] | 09.2013- |
| MAZDA | 3 1.6 | [Z6Y3] | 09.2013- |
| MAZDA | 3 1.6 MZR | [Z668] | 12.2008-09.2014 |
| MAZDA | 3 1.6 MZR | [Z682] | 12.2008-09.2014 |
| MAZDA | 3 1.6 MZR | [Z683] | 12.2008-09.2014 |
Reference Information
140.536.103.138 ZJ38-18-400 CGB-54246 9621 336108 115639 ZYF2-18-400 88213948 0986CN1623 324072102 221173A PRSS441 SMI266A 19226N 140.536.103.780 140.536.103.461 MAV372660 STM1353 101469 LRS2574 MA9027 M0T32771 140.536.103.265 8EA011611-951 STRS441 CST35266GS STR5228 11040843 M000T33971 10035266AV M000T32771AM 25-4246 MAV372660A STX200485R STR71327 J5213056 3111561 3111562 10438280 DRS0483 UD102462S ZJ38 5035755 STM0124 M0T33971 A25290 12693 S12MH0408A2 6035266.0 AZMT-53-010-1516 6035266.1 M000T32771 20437662BN STX200485 116275 ST02022 91-27-3548 LRS02574 803-11081 EST-4511 12377 20437662OE 063721469010 0986CR1623 9773 107244 10035266OV AC-CBS1469 SMI266 S12MH0408 MITM0T32771 0986025290 CS1469 101469M CST35266AS 324089102 M0T32771AM MQS1469 S103380 30155N 140.536.103.130 693ST21 140.536.103.371 140.536.103.370Video/Publications
