Remanufactured AS-PL Starter motor
STANDARD LINE
AS-PL
MAGNETON
Price:
NZ$ 369.09 including GST
NZ$ 320.95 excluding GST
or four payments of $92.27
with
Learn More
each
S9024SR
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 3 kW |
| Length (L.1) | 232 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| Mount Hole Diameter (C.3) | 10.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 10. 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 49 mm |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | MAGNETON |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHANG FENG | 3320 | 01.1992- | |
| URSUS | C-330 | 01.1967-12.1987 | |
| URSUS | C-330M | 07.1986-12.1993 | |
| URSUS | C-360 | 07.1976-12.1992 | |
| VALMET | 305 | 01.1985-12.1989 | |
| VALMET | 405 | 01.1985- | |
| VALMET | 505 3.3 | 01.1985- | |
| VALMET | 6000 | 01.1990- | |
| VALMET | 605 3.3 | 01.1985- | |
| VALMET | 6400 | 01.1991- | |
| VALMET | 6600 | 01.1991- | |
| VALMET | 705 4.4 | 01.1985- | |
| VALMET | 8050 | [620DS] | 01.1996- |
| VALMET | 805 4.4 | 01.1985- | |
| VALMET | 8100 | 09.1990- | |
| VALMET | 8150 | [620DS] | 01.1996- |
| VALMET | 8400 | [620DS] | 01.1993-12.1995 |
| VALMET | 8450 | [620DW] | 01.1996- |
| VALMET | 8550 | [634DS] | 01.1996- |
| VALMET | 8750 | [634DA][634DS] | 01.1996-12.1998 |
| VALMET | 8950 | [634DS] | 01.1998- |
| VALMET | 905 | 01.1985- | |
| ZETOR | 3321 | 01.1997- | |
| ZETOR | 3340 | 01.1992- | |
| ZETOR | 3341 | 01.1997- | |
| ZETOR | 4718 | 01.1974-01.1981 | |
| ZETOR | 7320 | 01.1992- | |
| ZETOR | 7321 | 01.1992- | |
| ZETOR | 7340 | 01.1992- | |
| ZETOR | 7341 | 01.1997- | |
| ZETOR | 7745 3.9 | 01.1988-01.2003 |
Reference Information
110545 DRS3690 0001359124 AES1147 220238 11.130.692 STG3742 11.130.179 26432 MS91 800.001.113.031 800.001.113.310 836640940 LRS00926 35259360 10604R R11.10 8EA730174-001 836662073 STRS526 33521 10944 26284 443115144722 NSB523 11.131.249 443115144729 R11.06 63227512 80350911 800.001.113.320 6048106.1 CGB-23147 6048106.0 0986013691 8710 0986013690 25-0315 S12308622 9142741 20500147 UD16660S 25-0430 27587 4412894 976116 800.001.113.010 976117 STRX725 976111 STR60413 800.001.113.030 CST48106AS IS0897 27512 443115142722 20408601BN 8EA737089-001 933253 443115144620 MAV3650 AZJ3599 AZJ3234 0001367067 LRS1088 AZJ3119 1208086 123708003 0001359047 3539390M91 91455722 PRSS526 11.130.376 11.130.414 8710R 800.001.113.351 CS604 LRS147 69185771 R11A R11F MAV501060 26242 9142722 R11N 443115144520 LES0006 S9024 27512D STR31000 27512A 27512B STX200715 27512F 9144722 LRS926 R11.01 26342D 114254 26342A LRS01088 8212915 835331592 CST48106GS 26342K 8813690 CS944 0001367032 02914502 AZJ3405 MS184 19677130A AZJ3525 447115144722 10604 LRS00147 R11 26342 33783 26284A STX200691 443115144420 26284E 26284B 20408601OE 443115144142 800.001.113.460Video/Publications
