Associated Numbers
|
041933 |
Da Silva |
|---|---|
|
12187645 |
PSA |
|
510515103 |
PSH |
|
KTR1021030206 |
KTR |
|
M100R2004AM |
Prestolite |
|
M100R2004SE |
Prestolite |
|
M100R2004SESEL |
+line |
|
PREM100R2004SE |
Wood Auto |
|
S133529 |
Short code |
|
S144398 |
Short code |
|
S163876 |
Short code |
|
STR81078 |
Wood Auto |
|
STR9727sa |
Electrolog |
|
WOOSTR81078 |
Wood Auto |
Specifications
Oil Sealed
| Kilowatt | 4.0 kW |
| Length (L.1) | 235 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 22 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FENDT | Farmer 103 | 01.1972-05.1982 | |
| FENDT | Farmer 103S | 01.1972-05.1982 | |
| RENAULT AGRICULTURE | 103-12 | [D226-4] | |
| RENAULT AGRICULTURE | 103-14 | [D226-4] | |
| RENAULT AGRICULTURE | 110-14 | [D226-6] | |
| RENAULT AGRICULTURE | 113-12 | [D226-6] | |
| RENAULT AGRICULTURE | 113-14 | [D227-6] | |
| RENAULT AGRICULTURE | 1151-4 | [115CV] | |
| RENAULT AGRICULTURE | 1181-4 | [118CV] | |
| RENAULT AGRICULTURE | 120-14 | [D226-6] | |
| RENAULT AGRICULTURE | 120-54 | [D226-6] | |
| RENAULT AGRICULTURE | 133-14 | [D226-6] | |
| RENAULT AGRICULTURE | 133-54 | [D226-6] | |
| RENAULT AGRICULTURE | 145-14 | [D228-6] | |
| RENAULT AGRICULTURE | 145-54 | [D228-6] | |
| RENAULT AGRICULTURE | 21520 | [D226-3] | |
| RENAULT AGRICULTURE | 22616 | [60CV] | |
| RENAULT AGRICULTURE | 24077 | [D226-3] | |
| RENAULT AGRICULTURE | 25173 | [68CV] | |
| RENAULT AGRICULTURE | 25903 | [D226-4] | |
| RENAULT AGRICULTURE | 27729 | [D226-4] | |
| RENAULT AGRICULTURE | 29556 | [D226-4] | |
| RENAULT AGRICULTURE | 301 | [30CV] | |
| RENAULT AGRICULTURE | 31382 | [D226-4] | |
| RENAULT AGRICULTURE | 35034 | [D226-4] | |
| RENAULT AGRICULTURE | 351 | [35CV] | |
| RENAULT AGRICULTURE | 361 | [36CV] | |
| RENAULT AGRICULTURE | 421 | [42CV] | |
| RENAULT AGRICULTURE | 456 | [46CV] | |
| RENAULT AGRICULTURE | 460 | [48CV] | |
| RENAULT AGRICULTURE | 461 | [46CV] | |
| RENAULT AGRICULTURE | 462 | [46V] | |
| RENAULT AGRICULTURE | 480 | [56CV] | |
| RENAULT AGRICULTURE | 486 | [51CV] | |
| RENAULT AGRICULTURE | 489 | [51CV] | |
| RENAULT AGRICULTURE | 490 | [65CV] | |
| RENAULT AGRICULTURE | 496 | [82CV] | |
| RENAULT AGRICULTURE | 498 | [90CV] | |
| RENAULT AGRICULTURE | 50 | [30CV] | |
| RENAULT AGRICULTURE | 50 | [33CV] | |
| RENAULT AGRICULTURE | 51 | [44CV] | |
| RENAULT AGRICULTURE | 53 | [30CV] | |
| RENAULT AGRICULTURE | 551 | [55CV] | |
| RENAULT AGRICULTURE | 551-4 | [55CV] | |
| RENAULT AGRICULTURE | 556 | [55CV] | |
| RENAULT AGRICULTURE | 56 | [46CV] | |
| RENAULT AGRICULTURE | 58-14 | [D226-3] | |
| RENAULT AGRICULTURE | 58-32 | [D226-3] | |
| RENAULT AGRICULTURE | 58-34 | [D226-3] | |
| RENAULT AGRICULTURE | 60 | [46CV] | |
| RENAULT AGRICULTURE | 61-14 | [60CV] | |
| RENAULT AGRICULTURE | 651 | [65CV] | |
| RENAULT AGRICULTURE | 65-14 | [D226-3] | |
| RENAULT AGRICULTURE | 651-4 | [65CV] | |
| RENAULT AGRICULTURE | 652 | [65CV] | |
| RENAULT AGRICULTURE | 65-32 | [D226-3] | |
| RENAULT AGRICULTURE | 65-34 | [D226-3] | |
| RENAULT AGRICULTURE | 656 | [65CV] | |
| RENAULT AGRICULTURE | 681 | [68CV] | |
| RENAULT AGRICULTURE | 68-14 | [68CV] | |
| RENAULT AGRICULTURE | 70 | [46CV] | |
| RENAULT AGRICULTURE | 70-14 | [D226-4] | |
| RENAULT AGRICULTURE | 70-32 | [D226-4] | |
| RENAULT AGRICULTURE | 70-34 | [D226-4] | |
| RENAULT AGRICULTURE | 75-14 | [D226-4] | |
| RENAULT AGRICULTURE | 751-4 | [75CV] | |
| RENAULT AGRICULTURE | 75-32 | [D226-4] | |
| RENAULT AGRICULTURE | 75-34 | [D226-4] | |
| RENAULT AGRICULTURE | 781 | [78CV] | |
| RENAULT AGRICULTURE | 80 | [55CV] | |
| RENAULT AGRICULTURE | 80-14 | [D226-4] | |
| RENAULT AGRICULTURE | 82 | [51CV] | |
| RENAULT AGRICULTURE | 851 | [85CV] | |
| RENAULT AGRICULTURE | 85-14 | [D226-4] | |
| RENAULT AGRICULTURE | 85-32 | [D226-4] | |
| RENAULT AGRICULTURE | 85-34 | [D226-4] | |
| RENAULT AGRICULTURE | 86 | [55CV] | |
| RENAULT AGRICULTURE | 89 | [58CV] | |
| RENAULT AGRICULTURE | 891 | [89CV] | |
| RENAULT AGRICULTURE | 90 | [62CV] | |
| RENAULT AGRICULTURE | 90 | [65CV] | |
| RENAULT AGRICULTURE | 90-32 | [D-226-4] | |
| RENAULT AGRICULTURE | 90-34 | [D-226-4] | |
| RENAULT AGRICULTURE | 91 | [72CV] | |
| RENAULT AGRICULTURE | 92 | [62CV] | |
| RENAULT AGRICULTURE | 94 | [80CV] | |
| RENAULT AGRICULTURE | 951 | [95CV] | |
| RENAULT AGRICULTURE | 95-14 | [D226-4] | |
| RENAULT AGRICULTURE | 96 | [90CV] | |
| RENAULT AGRICULTURE | 98 | [90CV] | |
| RENAULT AGRICULTURE | 981 | [98CV] |
Reference Information
10550K D11E158 S9043 25-0337 7700525547 18460N S12BH0278A2 351 STRS258 F13590206001 8647 DRS1020 433314 433315 7700519797 STX210075 CST10240ES STRS085 STR22088 LRS632 LRS639 9142801 CST10235AS AZJ3218 111332 IS0669 8031 IS0706 7700627394 LRS568 33513 IS0664 310415 310416 6010235 CGB-21210 103425 LRS00639 LRS00632 6005701125 MAV122350 12187645 943252276 MSN697 6010240 DRS3696 11.130.669 20401532BN 11.130.706 EAA-111449 25-0413 6005011729 CS1173 20401042EL H0641523 6005003152 6005003153 CST10240AS 220307 MS 570.001.093 MAV122400 8EA737722-001 25-1178 7700501670 X830100009 X830100006 X830100009000 911020 D11E120 STRX737 7700525064 8EA726182-001 LRS00568 101173 G514900060100 20401042BN F135902060010 101173K M100R2004SE 120-6022 10550 339 D11E131 AZJ3244 432569 STR7826 C514900060100 MSR737 33420 1.301E+11 CS550 7700026780 8811020 7700046893 432572View your shopping basket or Browse other items in Starter Motors.
