Price:
NZ$ 924.52 including GST
NZ$ 803.93 excluding GST
or four payments of $231.13
with
Learn More
each
A3796S
No stock in NZ
No stock in NZ
Specifications
| Amp | 180 A |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 9 mm |
| Diameter (D.4) | 9 mm |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 64.5 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 C7 3.0 TFSi Allroad Quattro | [CREC] | 09.2014-09.2018 |
| AUDI | A6 C7 3.0 TFSi Quattro | [CREC] | 09.2014-09.2018 |
| AUDI | A7 3.0 TFSi Quattro Sportback | [CREC] | 05.2014-05.2018 |
Reference Information
LRA4281 06E903024MX 40145 28-7890 AL04149 06E903024H 21961N WG2471726 LRA04281 ANM100060 06E903024M EG18S016 554696RIV 715189 6E903024H 2620983A 305.990.180.000 VAL439951 6E903024HX 6E903024M 89216500 AU8101 G103832 20015060OV 2015060.1 439951 305.990.180.500 440708 911ST75 12090934 06E903024HX 2715189A EG18S027 ALT00991 6E903024MX UD101071A 57911 ALTJ235 20179060OE CAL15060GS ALT170600 2115621802 AVA060 ALV9951View your shopping basket or Browse other items in Alternators.
