Price:
NZ$ 506.07 including GST
NZ$ 440.06 excluding GST
or four payments of $126.52
with
Learn More
each
S01061(SEG)
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 240 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Center - Center (O.2) | 84 mm |
| Mount Hole Center - Center (O.3) | 84 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | -5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 66 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | Jumper 2.5 D | [T9A(DJ5)] | 03.1994-04.2002 |
| CITROEN | Jumper 2.5 D | [T9A(DJ5)] | 08.1994-04.2002 |
| CITROEN | Jumper 2.5 D 4x4 | [T9A(DJ5)] | 03.2000-04.2002 |
| CITROEN | Jumper 2.5 D 4x4 | [T9A(DJ5)] | 08.1996-04.2002 |
| CITROEN | Jumper 2.5 TD | [T8A(DJ5T)] | 03.1994-04.2002 |
| CITROEN | Jumper 2.5 TD | [T8A(DJ5T)] | 08.1994-04.2002 |
| CITROEN | Jumper 2.5 TD 4x4 | [T8A(DJ5T)] | 08.1996-04.2002 |
| CITROEN | Jumper 2.5 TDi | [THX(DJ5TED)] | 12.1996-04.2002 |
| CITROEN | Jumper 2.5 TDi | [THX(DJ5TED)] | 12.1996-11.2000 |
| CITROEN | Jumper 2.5 TDi 4x4 | [THX(DJ5TED)] | 03.2000-04.2002 |
| CITROEN | Jumper 2.5 TDi 4x4 | [THX(DJ5TED)] | 12.1996-11.2000 |
| CITROEN | XM 2.5 TD | [THY(DK5ATE)] | 05.1994-10.2000 |
| PEUGEOT | 605 2.5 TD | [THY(DK5ATE)] | 07.1994-09.1999 |
| PEUGEOT | Boxer 2.5 D | [T9A(DJ5)] | 03.1994-04.2002 |
| PEUGEOT | Boxer 2.5 D | [T9A(DJ5)] | 08.1994-04.2002 |
| PEUGEOT | Boxer 2.5 D 4x4 | [T9A(DJ5)] | 07.1996-04.2002 |
| PEUGEOT | Boxer 2.5 D 4x4 | [T9A(DJ5)] | 07.1999-04.2002 |
| PEUGEOT | Boxer 2.5 TD | [T8A(DJ5T)] | 03.1994-12.1997 |
| PEUGEOT | Boxer 2.5 TD | [T8A(DJ5T)] | 07.1994-12.1997 |
| PEUGEOT | Boxer 2.5 TD 4x4 | [T8A(DJ5T)] | 07.1996-04.2002 |
| PEUGEOT | Boxer 2.5 TDi | [THX(DJ5TED)] | 01.1997-04.2002 |
| PEUGEOT | Boxer 2.5 TDi 4x4 | [THX(DJ5TED)] | 01.1997-04.2002 |
| PEUGEOT | Boxer 2.5 TDi 4x4 | [THX(DJ5TED)] | 07.1999-04.2002 |
Reference Information
TT15574 5802CT 5802L7 BREF032112053 5802L8 5802H5 5802H6 96253824 S27171 10010311OV 0001223001 5802CL 112053 ANM12271X DRS0051 9625382480 769ST11 M002T84771 TC9024 0986016950 20401113OE 5802M5 K1475489080 STB0885 20401113BN SM2616 CST10311GS M002T80582 M7T84771 1475489080 AZMT-53-010-1431 10010311AV 220.512.093.500 S100248 CST10311AS 5802F6 5802F7 220.512.093.460 BREF0320986016950 20401113RC 11769 M007T84771 UD04252(SEG)S 0001218157 6010311.2 PRSS021 6010311.1 SBO311 CST10311RS 6010311.0 M2T80582 11016950 F032112053 147363808 0001218757 DRS6950 220.512.093.215 AZMT-53-010-1589 14754890 K9625382480 147548908 STR10316 STRS021 220.512.093.010 1473638080 5802G4 220.512.093.011 1516821R K9611705880 M2T84771 K1473638080 192987 5802S8 0001109364 CGB-26950 0001109443 9611705880View your shopping basket or Browse other items in Starter Motors.
