Price:
NZ$ 433.77 including GST
NZ$ 377.19 excluding GST
or four payments of $108.44
with
Learn More
each
S0185(SEG)
No stock in NZ
No stock in NZ
Specifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 200 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Center - Center (O.2) | 64 mm |
| Mount Hole Center - Center (O.3) | 64 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10X1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 14 mm |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Fiesta 1.3 | [A9JA] | 11.2001- |
| FORD | Fiesta 1.3 | [A9JB] | 11.2001- |
| FORD | Fiesta 1.3 | [BAJA] | 11.2001- |
| FORD | Ka 1.3 i | [A9A] | 08.2002-06.2003 |
| FORD | Ka 1.3 i | [A9B] | 08.2002-06.2003 |
| FORD | Ka 1.3 i | [BAA] | 09.1996-10.2002 |
| FORD | Ka 1.6 i | [CDB] | 07.2003- |
| FORD | Ka 1.6 i | [CDC] | 07.2003- |
| FORD | Ka 1.6 Street | [CDRA] | 02.2003- |
| FORD | Ka 1.6 Street | [CDRB] | 02.2003- |
| FORD | Streetka 1.6 i | 12.2002- |
Reference Information
0001107501 11020900 105355 20401404BN 5010270 3120 3S65-11000-BA S513018 DSN3002 1149703 ANM23120 STX200258R TT15320 2S6U-11000-DA S1347B 1564732 0001107502-R 2S6U-11000-DB 2S6U-11000-DC 201050 319056102 20401404RC STA0357R CST10404GS UD04183(SEG)S 13652 11994 590.534.103.000 458447 220411 1871851 BREF0320986020900 590.534.103.010 LRS1700 SG0811RB QRS1288 SBO404A S12BH0368A2 333008 F004A94410 S102378 4S69-11000-AA STRS261 CST10404RS 32708N 114162 32708R 590.534.103.260 3N2T-11000-AB 25-3250 STX200258 0001107502 CST10404AS ST01315 RE2S6U-11000-DC DRT0900 WG2196627 3122849 3122848 IR9573 20401404OE S100063 10439785 10010404AV A20900 8EA738132-001 101587 0001107418 438421 LRS01700 94114DB 0001107410 10010404RV WG2170223 CS1289 BOL-B021097 1309581 590.534.103.280 FO9065 H5010270 42020900 RE83536N 88212761 V25-12-20900 0986020900 STR1275 F032114162 8EA012527-501 BST2097 TT15320PRO PRSS261 6010404.0 063721289010 6010404.2 6010404.1 101289 SG0811 994ST11 1648220380 AEU1289 944280801100 BREF032114162 STR50302 ANM23120X WG2012961 590.534.103.341View your shopping basket or Browse other items in Starter Motors.
