Price:
NZ$ 223.15 including GST
NZ$ 194.04 excluding GST
or four payments of $55.79
with
Learn More
each
S9836S
No stock in NZ
No stock in NZ
Specifications
| Length (L.1) | 157 mm |
| Mount Hole Center - Center (O.1) | 48 mm |
| Mount Hole Diameter (C.1) | 6.5 mm |
| Mount Hole Diameter (C.2) | 6.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 37 mm |
| Rotation | ACW |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| YAMAHA | MT-03 | [321cc] | 01.2016- |
| YAMAHA | MT-03 | [321cc] | 01.2017- |
| YAMAHA | MT-03 | [321cc] | 01.2018- |
| YAMAHA | MT-03 | [321cc] | 01.2019- |
| YAMAHA | MT-03 | [321cc] | 01.2020- |
| YAMAHA | MT-03 | [321cc] | 01.2021- |
| YAMAHA | YZF-R3 | [321cc] | 01.2015- |
| YAMAHA | YZF-R3 | [321cc] | 01.2016- |
| YAMAHA | YZF-R3 | [321cc] | 01.2017- |
| YAMAHA | YZF-R3 | [321cc] | 01.2018- |
| YAMAHA | YZF-R3 | [321cc] | 01.2019- |
| YAMAHA | YZF-R3 | [321cc] | 01.2020-12.2020 |
| YAMAHA | YZF-R3 | [321cc] | 01.2021-12.2021 |
| YAMAHA | YZF-R3 Monster | [321cc] | 01.2020- |
| YAMAHA | YZF-R3 Moto GP | [321cc] | 01.2017- |
| YAMAHA | YZF-R3 Moto GP Edition | [321cc] | 01.2015- |
| YAMAHA | YZF-R3 Moto GP Edition | [321cc] | 01.2019- |
Reference Information
