Associated Numbers
- BOSCH SR6537X
- CHRYSLER MOTORS 56029780AB, 56029780AC, 56029780AD
- DENSO 438000-2650, 438000-2651, 438000-2652, TN438000-2652 SAM-C11056
- TN4380002650 TN4380002651 TN4380002652
- LESTER 16431
-
BBB Industries 19285 Bosch Reman SR6537X Bosch Service Europe 0-986-UR1-896 Chrysler 5602 9780AD, 56029780AB, 56029780AC DENSO 438000-265, 438000-2650, 438000-2651 Dixie Electric Ltd S-80584 Dodge 56029780AB, 56029780AC, 56029780AD IAT 610-16431 Industry 16431 Lester 16431 PIC 190-6541 Standard Starter Drive 443442 TYC 1-16431 Voltux V1-16431 Wilson 91-29-5871 -
4380002650 Denso 56029780AB Chrysler 830416112 PSH
Specifications
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | M8x1.25 mm |
| Kilowatt | 1.3 kW |
| Length (L.1) | 220 mm |
| Mount Hole Center - Center (O.1) | 80 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 34 mm |
| Rotation | CW |
| Spigot Diameter (A) | 68 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | |||
| DODGE | |||
| JEEP |
Reference Information
56029780AB, 56029780AC, 56029780AD
